Artesyn iHP - B.2 MODULE Command Reference

iHP Manual 136 | P a g e
iHP Owners Manual
Command
Code
Command Name
Definition
Bit8
Bulk Short Circuit3
Bit7
Bulk Short Circuit2
Bit6
Bulk Short Circuit1
Bit5
Bulk Under Voltage Protection Rail3
Bit4
Bulk Under Voltage Protection Rail2
Bit3
Bulk Under Voltage Protection Rail1
Bit2
Bulk Over Voltage Protection Rail3
Bit1
Bulk Over Voltage Protection Rail2
Bit0
Bulk Over Voltage Protection Rail1
PFC Command Data Classifications
Command
Code
Command Name
Transaction
Type
# of Bytes
Data
Format
Write
Protection
03h
CLEAR_FAULTS
Send Byte
0
N/A
Basic
10h
WRITE_PROTECT
Read/Write
Byte
1
Bitmapped
N/A
78h
STATUS_BYTE
Read Byte
1
Bitmapped
N/A
79h
STATUS_WORD
Read Word
2
Bitmapped
N/A
7Ah
STATUS_VOUT
Read Byte
1
Bitmapped
Basic
7Ch
STATUS_INPUT
Read Byte
1
Bitmapped
Basic
7Dh
STATUS_TEMPERATURE
Read Byte
1
Bitmapped
Basic
7Eh
STATUS_CML
Read Byte
1
Bitmapped
Basic
80h
STATUS_MFR_SPECIFIC
Read Byte
1
Bitmapped
Basic
99h
MFR_ID
Block Read
7
ASCII
N/A
9Ah
MFR_MODEL
Block Read
15
ASCII
N/A
E0h
FW_PRI_VERSION
Block Read
8
ASCII
N/A
E9h
MFR_STATUS_01
Block Read
2 bytes per
index
Bitmapped
N/A
Note: 24kW iHP rack is composed of two boards of 12kW PFC.
In PFC PMBUS Commands,
 IOUT refers to the Output current of the PFC in which the command is addressed.
 VOUT refers to the Output voltage of the PFC in which the command is addressed.
 VIN refers to the Input Voltage of the PFC in which the command is addressed.
 IIN refers to the Input Current of the PFC in which the command is addressed.
B.2 MODULE Command
