 have positive terminals connected in parallel.
 have negative terminals connected in parallel.
 have “SYS_RTN” signals (Module’s J1 Pin8) star connected.
 have “0-10VEXT_VPROG” signals (Module’s J1 Pin1) star connected if system will be operating using 0-
10VEXT_VPROG.
 have “0-5VEXT_VPROG” signals (Module’s J1 Pin2) star connected if system will be operating using 0-
5VEXT_VPROG.
The module will clamp into constant voltage if the requested output current or load resistance increases and
causes the output voltage to be greater than the VREF. If operating from this condition connect:
 All Module “REMOTE_SENSE_+” should be star connected and connected to the desired point of
regulation.
 All Module “REMOTE_SENSE_-” should be star connected and connected to the desired point of
regulation.
 All Module “ISHARE” signal (Module’s J2 pin 10) should be star connected.
 All Module “A_RTN” signal (Module’s J2 pin 4) should be start connected.
Warning! - Module’s J2 signals and output voltage are isolated from module’s J1 signals.
4.5.3.3.1 AVS Series Connection Protection
Each individual module in a group will protect independently and will protect as stated in Section 4.5.2.
