iHP Manual 94 | P a g e

iHP Owners Manual

RACK Synchronized Off Setting

Remarks

Enable

Rack synchronize off is activated

Disable

Rack synchronize off is de-activated

Number of racks connected will be activated when the Rack Synchronized OFF is enabled. This parameter will

indicate how many racks should be synchronized. Allowable racks to be synchronized is up to six racks.

5.1.4 Module Section

In this section, user can configure multiple modules installed in the iHP rack as one.
