Command to indicate module present in the iHP RACK
Data Bit0 : Asserted when module is present in slot1
Data Bit1 : Asserted when module is present in slot2
Data Bit2 : Asserted when module is present in slot3
Data Bit3 : Asserted when module is present in slot4
Data Bit4 : Asserted when module is present in slot5
Data Bit5 : Asserted when module is present in slot6
Data Bit6 : Asserted when module is present in slot7
Data Bit7 : Asserted when module is present in slot8
Command used to Save below Module Configuration.
48h, 49h, 4Bh, 4Ch, 4Dh, 4Eh, 52h, 53h, 54h, B4h B5h, B6h, B7h, B8h, B9h,
Bah, D3h, F9h, FAh
This command have indicates the module slot or Group number in which the
setting will be implemented
data = “00” = Slot 1 module
data = “01” = Slot 2 module
data = “02” = Slot 3 module
data = “03” = Slot 4 module
data = “04” = Slot 5 module
data = “05” = Slot 6 module
data = “06” = Slot 7 module
data = “07” = Slot 8 module
data = “08” = GROUP1 module
data = “09” = GROUP2 module
data = “0A” = GROUP3 module
data = “0B” = GROUP4 module
data = “0C” = GROUP5 module
data = “0D” = GROUP6 module
data = “0E” = GROUP7 module
After sending this PMBUS command, All modules will shut down and restart
again.
