X = 48.12 V

Example 2

Module Command 8Ch (READ_IOUT)

# of byte = 3 Byte

Multiplier = N = 10000

COMMAND 8Bh returns a data of 098968h

Convert 098968h to decimal = 625000

Y = X * N

625000 = X * 10000

X = 62.5A

Example 3

Module Command 48h (OV_FAULT_LIMIT_MULTIPLIER)

# of byte = 2 Byte

Multiplier = N = 100

COMMAND 48h returns a data of 2EE0h

Convert 2EE0h to decimal = 12000

Y = X * N

12000 = X * 100

X = 120%
