iHP Manual 188 | P a g e

iHP Owners Manual

Here are the settings of each module based on latest config (ini) file:

24V

48V

80V

125V

250V

VOR Clamp

1.087V

2.174V

3.6233V

6.0388V

11.4421V

Brick Wall OVP

31.3V

64.5V

110V

162V

315V

 VOR clamp level based on actual module read back

 Brick Wall OVP calculated based on DSP pin voltage

 Values may vary between units due to effects of calibration since both settings are based on DSP pin

voltages
