ASL INTERCOM VAR4 - Page 287

VAR4 / VAR12 / VAR20 - Operation Manual
Is
Page 287 of 308
sue: 03 complete, approved
Fault Description
Fault Code(s)
Reported and Logged
Suggested Action
DSP comms failure
or
DSP / M16C CPU
command interface
compatibility errors, from
V4.1.0470 or later
VARNN/X FAULT-03
NN=01 to 30 (VAR ID)
X=1=Base unit board
2=Expansion board 1 (VAR12)
3=Expansion board 2 (VAR20)
VAR Router will need replacing.
DSP / M16C CPU
command interface
compatibility errors
VARNN/X FAULT-04
NN=01 to 30 (VAR ID)
X=1=Base unit board
2=Expansion board 1 (VAR12)
3=Expansion board 2 (VAR20)
VAR Router will need replacing.
From V4.1.0470 or later, this fault will be reported as
FAULT-03.
M16C CPU failures of
the second or third
board in a VAR12 or
VAR20
VARNN/X FAULT-05
NN=01 to 30 (VAR ID)
X=2=Expansion board 1 (VAR12)
3=Expansion board 2 (VAR20)
VAR Router will need replacing.
Hardware override path
failures
VARNN/X FAULT-06
NN=01 to 30 (VAR ID)
X=1=Base unit board
2=Expansion board 1 (VAR12)
3=Expansion board 2 (VAR20)
VAR Router will need replacing.
NN=01 to 30 (VAR ID)
AC97 (digital audio) bus
1 failures on the bottom
and top expansion
boards
VARNN/X FAULT-07
X=2=Expansion board 1 (VAR12)
3=Expansion board 2 (VAR20)
VAR Router will need replacing.
AC97 (digital audio) bus
2 failures on the bottom
and top expansion
boards
VARNN/X FAULT-08
NN=01 to 30 (VAR ID)
X=2=Expansion board 1 (VAR12)
3=Expansion board 2 (VAR20)
VAR Router will need replacing.
M16C CPU and DSP
memory fault
VARNN/X FAULT-09
NN=01 to 30 (VAR ID)
X=1=Base unit board
2=Expansion board 1 (VAR12)
3=Expansion board 2 (VAR20)
VAR Router will need replacing.
Comms fault with Router
expansion board on
VAR12 or VAR20
VARNN/X FAULT-11
NN=01 to 30 (VAR ID)
X=1=Base unit board
2=Expansion board 1 (VAR12)
3=Expansion board 2 (VAR20)
VAR Router will need replacing.
DSP Codec fault VARNN/1 FAULT-12
NN=01 to 30 (VAR ID)
VAR Router will need replacing.
DSP interrupt fault VARNN/X FAULT-13
NN=01 to 30 (VAR ID)
X=1=Base unit board
2=Expansion board 1 (VAR12)
3=Expansion board 2 (VAR20)
VAR Router will need replacing.
