The maximum input pulse frequency is 200 kHz. If the 24V power is provided by yourself, no current
limit resistor is needed. Generally, the PLC from a Japanese manufacturer uses the NPN type, while
that from a European manufacturer uses the PNP type.
Open collector connection 2
Control module using NPN triodes with common cathode:
