Astraada SRV-64 - Outline Drawing

AS64 series AC servo drive Overview
-6-
1.1.2 Outline drawing
For standard model
CN2: Enco der
CN11: STO
CN1: I/O control
CN3: CA N/RS485 com mu nica tio n
CN4: Uppe r comp uter
LE D display
Operation pa nel
Mo tor
Ground ing
Rege nerativ e
resistor
Cont rol-circuit p ower
supply
Ma in-circuit po wer
supply
Charg e indicato r
CN5: Fully-closed loop
