AS64 series AC servo drive Control modes
-49-
Signal
Symbol
Function
Applicable
mode
PTP output 3
PTPO3
0x19
P
It is the signal of PTP output 3.
Signal
Symbol
Function
Applicable
mode
PTP output 4
PTPO4
0x1A
P
It is the signal of PTP output 4.
Signal
Symbol
Function
Applicable
mode
PTP output 5
PTPO5
0x1B
P
It is the signal of PTP output 5.
Signal
Symbol
Function
Applicable
mode
PTP output 6
PTPO6
0x1C
P
It is the signal of PTP output 6.
Signal
Symbol
Function
Applicable
mode
PTP output 7
PTPO7
0x1D
P
It is the signal of PTP output 7.
Signal
Symbol
Function
Applicable
mode
Gantry synchronization
cancellation output
GSC
0x1E
P
It is the output signal of gantry synchronization cancellation.
Signal
Symbol
Function
Applicable
mode
Dynamic brake relay control
DBRC
0x1F
P
S
T
It is the output signal of dynamic brake relay control.
4.4.5 Pulse input signals and functions
Sign
Pin
Signal
Function
OCP
38
