About this task
Note:
Unless otherwise prevented using administration, the user can view but not change most of
the parameters associated with Craft Local Procedures. For more information about this
option, see the applicable user guide(s). If the View Network Information option is not
available due to being disabled by administration, use the ADDR option to view IP Addresses.
The IP Addresses might have been entered incorrectly. Verify whether you were provided with
correct IP Addresses.
Procedure
1. Use the Craft password to gain access to the Administration procedures screen. The
default password is 27238.
2. Select VIEW from the Administration procedures screen. See View field descriptions for
more details.
3. Press Back at any time to return to the Administration procedures screen.
VIEW field description
Setting
Description Associated Configuration
Parameter
Model The model of the phone that is
set by factory procedures.
MODEL
Application File The name of the Signed
Application/Library software
package.
Boot File The name of the boot file.
Button modules The connected button module to
the phone. Button module is
supported only in Avaya J169/
J179 IP Phone.
FIPS The FIPS mode is displayed. FIPS_ENABLED
Protocol Signaling protocol in effect, such
as SIP.
Group The group identifier to download
during start-up a specific
configuration set for a dedicated
user group.
GROUP
MAC The MAC address of the phone. MACADDR
SIP Proxy Server The SIP proxy server to which the
phone registered successfully.
SIPPROXYSRVR_IN_ USE
Table continues…
VIEW field description
January 2020 Installing and Administering Avaya 9601/9608/9611G/9621G/9641G/9641GS IP
Deskphones SIP 73
Comments on this document? infodev@avaya.com
