Destination port Source port Use Protocol
UDP or TCP
FEPORT + 1 (if
FEPORT is even) or
FEPORT -1 (if FEPORT
is odd) or the port
number specified in a
CNA RTP test request
plus or minus one, as
with FEPORT
PORTAUD + 1 (if
PORTAUD is even) or
PORTAUD – 1 (if
PORTAUD is odd) or the
port number reserved for
CNA RTP tests plus or
minus one, as for
PORTAUD, above
RTCP packets
transmitted to the far-
end of the audio
connection
UDP
RTCPMONPORT PORTAUD + 1 (if
PORTAUD is even) or
PORTAUD – 1 (if
PORTAUD is odd)
RTCP packets
transmitted to an RTCP
monitor
UDP
System-specific Any unused port number Transmitted signaling
protocol packets
UDP
Preinstallation checklist for static addressing
Before performing static addressing, verify all the network requirements first. In addition, you must
have the values for the following parameters:
• IP address of the deskphone.
• IP address of the router.
• IP subnet mask.
• IP address of the HTTP and/or HTTPS server (applicable for only DHCP server settings).
• IP address of the DNS Server.
• VLAN ID (the L2QVLAN value).
• VLANTEST value.
Assigning static IP address
Use static IP addressing, if the setup does not require a DHCP server.
Procedure
1. In the Administration menu, go to ADDR.
2. In the IP Address field, enter the IP address. For the description of other fields, see Static
addressing field descriptions.
3. Use the navigation arrows to scroll to and highlight the address you want to change.
Choose one of the following options:
Preinstallation checklist for static addressing
January 2020 Installing and Administering Avaya 9601/9608/9611G/9621G/9641G/9641GS IP
Deskphones SIP 79
Comments on this document? infodev@avaya.com
