Avaya 9600 Series Installing And Administering

- Repeat steps to complete all four targets with the following message:Calibration
successful
4. Press Save to save the settings.
Using the Debug Mode
Before you begin
Ensure that the following values are changed:
• Value of PROCPSWD parameter is set to a value other than default. When the
ADMIN_PASSWORD is set, then the parameter PROCPSWD is not used.
• Value of SLMCAP parameter is set to “3”.
• Value of SLMCTRL parameter is set to “2”.
Procedure
1. Use the Craft password to gain access to the Administration procedures screen.
2. Navigate to DEBUG from the Administration procedures screen. The following debug
options are available:
• Debug Mode
• Service mode control
• Service mode record
3. To enable or disable the options, tap or use the appropriate buttons.
4. Press Save to store the new setting.
Restart the deskphone for the DEBUG settings to take effect.
Setting interface control
About this task
Use the following procedure to set or change the interface control value.
Procedure
1. Use the Craft password to gain access to the Administration procedures screen. The
default password is 27238.
2. When you select INT... from the Administration procedures screen, the following text
displays with a prompt to use the Right and Left navigation arrows to select a setting:
Ethernet: Choice Selector
Using the Debug Mode
January 2020 Installing and Administering Avaya 9601/9608/9611G/9621G/9641G/9641GS IP
Deskphones SIP 95
Comments on this document? infodev@avaya.com

Avaya 9600 Series Specifications

General

Brand	Avaya
Model	9600 Series
Category	IP Phone
Language	English
