HDMI Input Ports
HDCP Compliant
Yes
Table 1.3.1 Supported HDMI Input Format
To understand the format of resolution, it is shown in the format:
Width×Height (in pixels), p or i, Frame Rate (in Hz, or frames per second) where p means progressive
scanning, and i means interlaced scanning i.e. 3840×2160p 60Hz is 3840 pixels wide, 2160 pixels high,
progressive, and has a frame rate of 60Hz.
HDMI Output Ports
Signal Type
HDMI 2.0
Connectors
Five HDMI Type-A connectors for HDMI/DVI monitor (a HDMI to DVI adapter may be
needed)
Note:
1. Transmission of embedded audio signal is not supported when passing an
output signal through HDMI to DVI adapter.
2. Avitech recommends using a HDCP-compliant monitor for optimum performance.
Resolution
Supported resolutions include (but not limited to):
 3840×2160 (4K UHD) at 25Hz / 30Hz / 50Hz / 60Hz
 1920×1080 (FHD) at 50Hz / 60Hz
 1280×1024 (SXGA) at 50Hz / 60Hz
HDCP Compliant
Yes
Color Depth
8 bit
Display Mode
Supports five display mode:
 Workstation (Default): Supports simultaneous display of four signal sources in
multiview layout on the 1
st
output. Freely switch single-view fullscreen image, or
duplicated multiview layout image on the 2
nd
to 4
th
outputs. The 5
th
output can only
have one of the input signal source display single-view fullscreen image.
 Workstation (Quad + 4 Singles): Supports simultaneous display of four signal
sources in multiview layout, and freely switch to single-view fullscreen image on
the 1
st
output. Freely switch single-view fullscreen image on 2
nd
to 5
th
outputs.
 Video wall: Supports a 2x2 video wall or video walls with 1 row and 2 to 4 columns
with PiP display.
 Projector (PiP): Creates a preview multiview on the 1
st
output, and the 2
nd
to 5
th
outputs can duplicate two picture-in-picture (PiP) images.
 Projector (Fullscreen): Creates a preview multiview on the 1
st
output, and the 2
nd
to 5
th
outputs can duplicate two single-view fullscreen image for seamless
switching of the input sources.
Table 1.3.2 Supported HDMI Output Format
If the monitor’s EDID is not detected, the output resolution of Sequoia 4K60 will automatically configure to
3840×2160p at 60Hz (default setting).
Others
Computer
Up to four units (maximum for single Sequoia 4K60 system)
Port Switching
Method:
 Keyboard hotkeys in Host operation mode
 Mouse
 OSD (pop-up menu – in Host operation mode)
 “Surfer” feature (both in Host and Remote operation modes)
