3.5.3 (Optional) Basic Operation of the Multiview 4K UHD Screen
Depending on the application requirement, if only for video monitoring you may skip this section.
Host Mode
When the monitor connected to HDMI port marked OUT 1 of Sequoia 4K60 is in Host mode, the Host
cursor appears on the display upon connecting a mouse device to USB Type-A port marked 1of
Sequoia 4K60. The cursor will be controlled by this connected mouse.
Host mode provides a monitoring solution for the incoming computer/video signals. Users can use the
Host cursor to select and adjust window size, position, and display layout directly through the
on-screen interface.
Double-click the mouse left button any area within that specific window to enter the Remote mode (or
move the Host cursor to the top-right corner of the targeted window and then click the Enter remote
mode icon).
To switch back to Host mode, use the keyboard “Pause/Break” hotkey, or double-click the mouse
scroll button.
To route an input source to display on the monitor, use keyboard “Ctrl – 1 – (1 to 4)” hotkeys will load
input source to display on the monitor in fullscreen. For example, “Ctrl – 1 – 4” hotkey will switch input
source 4 to display in fullscreen; “Ctrl – 1 – 1” hotkey will switch input source 1 to display in fullscreen.
Upon re-connecting a keyboard or mouse, the Host cursor may disappear. Move the mouse to allow it to
re-appear.
Move the Host cursor to the top-right position, the pop-up selections will appear upon
moving the Host cursor to the top-right of each window.
Figure 3.5.3.1 Pop-up Selections of Quad-view Window
Or, when in fullscreen upon moving the Host cursor to the window’s top-right position, the pop-up
selections will appear.
Figure 3.5.3.2 Pop-up Selections of Fullscreen Window
