3.4.2 Basic Operation of HDMI Out Port 2 to HDMI Out Port 5
Host Mode
When the monitors connected to the HDMI ports marked OUT 2 – OUT 5 of Sequoia 4K60 is in Host
mode, the Host cursors appears on its corresponding display upon connecting a mouse device to one of
the USB Type-A ports marked 2 – 5 of Sequoia 4K60. The cursor will be controlled by its locally
connected mouse.
Double-click the mouse left button on the fullscreen window or click the Enter remote mode icon
to enter the Remote mode.
To switch back to Host mode, use keyboard “Pause/Break” hotkey, or double-click the mouse scroll
button.
Use keyboard “Ctrl – (2 to 5) – (1 to 4)” hotkey to route an input source to display on the monitor
connected to HDMI OUT port; for example “Ctrl – 3 – 4” hotkey will load input source 4 to display on
the monitor of HDMI OUT 3; “Ctrl – 5 – 1” hotkey will load input source 1 to display on the monitor of
HDMI OUT 5; “Ctrl – 2 – 2” hotkey will load input source 2 to display on the monitor of HDMI OUT 2.
Move the Host cursor to the top-right position, the pop-up selections will
appear. You can then switch source or enter to control the remote computer.
Figure 3.4.2.1 Pop-up Selections for HDMI OUT 3
Click icon or double-click the mouse left button to enter the Remote mode.
Click (input 1) – (input 4) icons to switch the input source.
Click icon (the audio currently in off state) to turn on the HDMI embedded audio. Click icon
(the audio currently is playing) to turn off the HDMI embedded audio.
1. The pop-up selections for / are greyed out due to the HDMI port marked OUT 2 – OUT 5 of
Sequoia 4K60 is fixed in fullscreen display in Workstation (Quad + 4 Singles) display mode.
2. When the INPUT # icon is greyed out, that means its source is currently displaying on the monitor.
3. When the icon is greyed out, that means the USB Type-B port of Sequoia 4K60 is not connected to a
computer's USB port.
Remote Mode
When entering Remote mode, the Host cursor disappears, and the “Surfer” feature is enabled. The
window’s border will turn yellow, this signifies that your Sequoia 4K60 is now in Remote mode with
“Surfer” feature.
Entering Remote mode, your Sequoia 4K60 transfers keyboard and mouse control to the selected
computer system.
