Connection to Multiview 4K UHD Screen
Step 1. To simultaneously view four computer sources on a quad-view layout on a large 4K UHD
screen, connect the port marked HDMI OUT 1 of the Sequoia 4K60 to the multiview 4K UHD
screen.
Step 2. (For video only application, you may skip this step) Connect a short USB extension cable or a
USB hub to the USB Type-A port marked 1 on the front panel of Sequoia 4K60 for
connection to a set of wireless keyboard/mouse; they will be used to control the four computer
sources.
1. It is strongly recommended using a powered USB Hub to prevent any drops in performance if you plan to
use a USB hub to support more USB devices i.e. keyboard, mouse and touch screen. If a powered USB
HUB is not available, you may use an unpowered USB 2.0 Hub instead.
2. Non-standard keyboards that require manual installation of drivers are not supported.
3. The Sequoia 4K60 automatically detects monitor's EDID. When your Sequoia 4K60 is connecting with
monitors support 4K UHD and FHD resolution and set the configuration to Projector (PiP) / Projector
(fullscreen) mode, please connect the monitors support FHD resolution to the ports marked HDMI OUT 2 / 4
to ensure the image display on all the monitors.
Connections to Projector 1 – Projector 4
Step 1. Connect the port marked HDMI OUT 2 on the front panel of Sequoia 4K60 to the HDMI port of
projector 1 using an appropriate signal cable.
Step 2. Connect the port marked HDMI OUT 3 on the front panel of Sequoia 4K60 to the HDMI port of
projector 2 using the appropriate signal cable.
Step 3. Connect the port marked HDMI OUT 4 on the front panel of Sequoia 4K60 to the HDMI port of
projector 3 using the appropriate signal cable.
Step 4. Connect the port marked HDMI OUT 5 on the rear panel of Sequoia 4K60 to the HDMI port of
projector 4 using the appropriate signal cable.
Powering Up the Devices
Step 1. Connect power to/and boot-up the four source computers.
Step 2. Connect power to the monitor / projectors and turn on the monitors.
Step 3. Connect the power adapter to the DC 12V/5A power in jack on the Sequoia 4K60, and press the
power switch so that the Sequoia 4K60 is turned on.
Step 4. The Avitech logo will appear briefly on the monitor, and after approximately 60 seconds the four
windows (each containing an image from one of the connected computers) will appear, along
with the Host cursor that can be controlled directly through the mouse connected to your
Sequoia 4K60's USB Type-A port marked 1.
For basic operation, please refer to section (3.5) “Basic Operation for Projector Configuration” for more
details.
