Specifications, Requirements, and Precautions AW00089317000
4 Basler ace GigE
Specification acA645-100gm/gc acA750-30gm/gc
Sensor Size
(H x V pixels)
gm: 659 x 494
gc: 658 x 492
gm: 752 x 580
gc: 748 x 576
Sensor Type Sony ICX414 AL/AQ
Progressive scan CCD
Global shutter
Sony ICX409 AL/AK
Interlaced scan CCD
Global shutter
Optical Size 1/2" 1/3"
Pixel Size (H x V) 9.9 µm x 9.9 µm 6.5 µm x 6.25 µm
Max. Frame Rate
(at full resolution)
100 fps 30 fps
Mono/Color Mono or color
(color models include a Bayer pattern RGB filter on the sensor)
Data Output Type Fast Ethernet (100 Mbit/s) or Gigabit Ethernet (1000 Mbit/s)
Pixel Data Formats Mono Models: Mono 8 YUV 4:2:2 Packed
Mono 12 YUV 4:2:2 (YUYV) Packed
Mono 12 Packed
Color Models:
Mono 8
Bayer BG 8
Bayer BG 12
Bayer BG 12 Packed
YUV 4:2:2 Packed
YUV 4:2:2 (YUYV) Packed
Color Models:
Mono 8
YUV 4:2:2 Packed
YUV 4:2:2 (YUYV) Packed
ADC Bit Depth 12 bits
Synchronization Via external trigger signal, via the Ethernet connection, or free run
Exposure Control Via external trigger signal or programmable via the camera API
Camera Power
Requirements
PoE (Power over Ethernet 802.3af compliant)
or
+12 VDC (± 10%), < 1% ripple, supplied via the camera’s 6-pin Hirose connector;
Cable must be at least a 26 AWG cable. Max. cable length: 10 m
~ 3.6 W when using Power over Ethernet
~ 3.3 W @ 12 VDC when supplied via
the camera’s 6-pin connector
~ 2.6 W when using Power over Ethernet
~ 2.4 W @ 12 VDC when supplied via
the camera’s 6-pin connector
I/O Ports 1 opto-isolated input line and 1 opto-isolated output line
Lens Adapter C-mount; CS-mount
Size (L x W x H) 42.0 mm x 29 mm x 29 mm (without lens adapter or connectors)
60.3 mm x 29 mm x 29 mm (with lens adapter and connectors)
Weight < 90 g
Table 2: General Specifications (acA645-100gm/gc, acA750-30gm/gc)
