Specifications, Requirements, and Precautions AW00089317000
6 Basler ace GigE
Specification acA780-75gm/gc acA1280-60gm/gc acA1300-22gm/gc
Sensor Size
(H x V pixels)
gm: 782 x 582
gc: 780 x 580
gm: 1282 x 1026
gc: 1280 x 1024
gm: 1296 x 966
gc: 1294 x 964
Sensor Type Sony ICX415 AL/AQ
Progressive scan CCD
Global shutter
gm: e2V EV76C560 ABT
gc: e2V EV76C560 ACT
Progressive scan CMOS
Rolling shutter
Sony ICX445 AL/AQ
Progressive scan CCD
Global shutter
Optical Size 1/2" 1/1.8" 1/3"
Pixel Size (H x V) 8.3 µm x 8.3 µm 5.3 µm x 5.3 µm 3.75 µm x 3.75 µm
Max. Frame Rate
(at full resolution)
75 fps gm: 60 fps
gc: 60 fps (only, if camera is
set for Bayer RG 8 format
and if GigE connection does
not limit the frame rate)
22 fps
Mono/Color Mono or color
(color models include a Bayer pattern RGB filter on the sensor)
Data Output Type Fast Ethernet (100 Mbit/s) or Gigabit Ethernet (1000 Mbit/s)
Pixel Data Formats Mono Models:
Mono 8
Mono 12
Mono 12 Packed
YUV 4:2:2 Packed
YUV 4:2:2 (YUYV) Packed
Color Models:
Mono 8
Bayer BG 12
Bayer BG 12 Packed
YUV 4:2:2 Packed
YUV 4:2:2 (YUYV)
Packed
Color Models:
Bayer RG 8
Bayer RG 12 (*)
Bayer RG 12 Packed (*)
YUV 4:2:2 Packed
YUV 4:2:2 (YUYV)
Packed
[(*) When using one of the
12 bit modes the two least
significant bits are set to 0.]
Color Models:
Mono 8
Bayer BG 8
Bayer BG 12
Bayer BG 12 Packed
YUV 4:2:2 Packed
YUV 4:2:2 (YUYV)
Packed
ADC Bit Depth 12 bits 10 bits, see (*) above 12 bits
Synchronization Via external trigger signal, via the Ethernet connection, or free run
Exposure Control Via external trigger signal
or programmable via the
camera API
Programmable via the
camera API
Via external trigger signal or
programmable via the
camera API
Table 3: General Specifications (acA780-75gm/gc, acA1280-60gm/gc, acA1300-22gm/gc)
