Basler GigE SERIES User Manual

Specifications, Requirements, and Precautions AW00089317000
8 Basler ace GigE
Specification acA1300-30gm/gc acA1300-60gm/gc acA1300-60gmNIR
Sensor Size
(H x V pixels)
gm: 1296 x 966
gc: 1294 x 964
gm: 1282 x 1026
gc: 1280 x 1024
Sensor Type Sony ICX445 AL/AQ
Progressive scan CCD
Global shutter
gm: e2V EV76C560 ABT
gc: e2V EV76C560 ACT
Progressive scan CMOS
Global shutter
Rolling shutter
The shutter mode can be
set via the software.
e2V EV76C661 ABT
Progressive scan CMOS
Global shutter
Rolling shutter
The shutter mode can be
set via the software.
Optical Size 1/3" 1/1.8"
Pixel Size (H x V) 3.75 µm x 3.75 µm 5.3 µm x 5.3 µm
Max. Frame Rate
(at full resolution)
30 fps gm: 60 fps
gc: 60 fps (only, if camera
is set for Bayer RG 8
format and if GigE
connection does not limit
the frame rate)
gmNIR: 60 fps
Mono/Color Mono or color
(color models include a Bayer pattern RGB filter on the sensor)
Data Output Type Fast Ethernet (100 Mbit/s) or Gigabit Ethernet (1000 Mbit/s)
Pixel Data Formats Mono Models:
Mono 8
Mono 12
Mono 12 Packed
YUV 4:2:2 Packed
YUV 4:2:2 (YUYV) Packed
Color Models:
Mono 8
Baye BG 12
Bayer BG 12 Packed
YUV 4:2:2 Packed
YUV 4:2:2 (YUYV)
Packed
Color Models:
Mono 8
Bayer RG 8
Bayer RG 12 (*)
Bayer RG 12 Packed (*)
YUV 4:2:2 Packed
YUV 4:2:2 (YUYV) Packed
[(*) When using one of the 12 bit modes the two least
significant bits are set to 0.]
ADC Bit Depth 12 bits 10 bits, see (*) above
Synchronization Via external trigger signal, via the Ethernet connection, or free run
Table 4: General Specifications (acA1300-30gm/gc, acA1300-60gm/gc, acA1300-60gmNIR)

Basler GigE SERIES Specifications

General

Interface	GigE
Lens Mount	C-Mount, CS-Mount
Sensor	CMOS
Mount	C-mount, CS-mount
Power Supply	Power over Ethernet (PoE)
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	Varies by model
