Standard Features AW00089317000
200 Basler ace GigE
acA2000-50 and acA2040-25 Only
The camera’s gain is determined by the value of the Gain Raw parameter. Gain Raw is adjusted on
an integer scale. The minimum setting varies depending on the camera model and on whether
vertical binning is enabled (see Table 29). The maximum setting depends on whether the camera
is set for a pixel data format that yields 8 bit effective pixel depth (Mono 8, Bayer xx 8, YUV 4:2:2
Packed, YUV 4:2:2 (YUYV) Packed) or yields an effective pixel depth of 12 bits per pixel (Mono 12,
Mono 12 Packed, Bayer xx 12, Bayer xx 12 Packed) [xx: either GB, BG or GR].
.
1. Set the Gain Selector to Gain All.
2. Set the Gain Raw parameter to your desired value.
You can set the Gain Selector and the Gain Raw parameter value from within your application
software by using the Basler pylon API. The following code snippet illustrates using the API to set
the selector and the parameter value:
Camera.GainSelector.SetValue( GainSelector_All );
Camera.GainRaw.SetValue( 400 );
You can also use the Basler pylon Viewer application to easily set the parameters.For more
information about the pylon API and the pylon Viewer, see Section 3 on page 45.
acA1300-22gm/gc
acA1300-30gm/gc
10.8 30.5 14.4
acA1600-60gm/gc 8.3 30.5 14.4
Camera Model Min Setting Min Setting with
Vertical Binning
(mono cameras)
Max Setting
(8 bit depth)
Max Setting
(12 bit depth)
acA2000-50gm/gc
36 33 512 512
acA2000-50gm/gc - CMV2000-V3
acA2000-50gmNIR
acA2000-50gmNIR - CMV2000-V3
acA2040-25gm/gc
acA2040-25gm/gc - CMV4000-V3
acA2040-25gmNIR
acA2040-25gmNIR - CMV4000-V3
Table 29: Minimum and Maximum Allowed Gain Raw Settings (acA2000-50, acA2040-25 Only)
To set the Gain Raw parameter value using Basler pylon:
Camera Model db Gain at Min Setting db Gain at Max Setting
(8 bit depth)
db Gain at Max Setting
(12 bit depth)
Table 28: Minimum and Maximum dB of Gain
