Basler GigE SERIES User Manual

Standard Features AW00089317000
240 Basler ace GigE
Fig. 99: Sequencer in Controlled Sequence Advance Mode with Always Active as the Sequence Control Source and
Synchronous Restart Controlled by Line 1
21 3 00 1 1 42 3
0
Signal Applied
to Input Line 1
(Restart)
= frame exposure and readout
= frame transmission
= camera is waiting for a frame start trigger
= camera selects a sequence set as the current sequence set
= current sequence set that is used for the image acquisition
(the sequence set index number is indicated)
Time
Frame Start
Trigger Signal
Sequencer
Enabled
Sequence Set Cycle
Starts Again
Sequence Set Cycle
Starts Again
Use Case: Operation in controlled sequence advance mode
with Always Active as the sequence control source:
Automatic cycling through the sequence set cycles
with two synchronous restartscontrolled by input
line 1.
Setting: Sequence Set Total Number = 6
Line 1 (not set for invert) is selected as the source
for controlling
restart

Basler GigE SERIES Specifications

General

Interface	GigE
Lens Mount	C-Mount, CS-Mount
Sensor	CMOS
Mount	C-mount, CS-mount
Power Supply	Power over Ethernet (PoE)
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	Varies by model
