Use
46
7990087_030_03 – 2080492 – 2023-01-19
– Depending on the variant, the swivel range and the vertical
travel is limited by the internal end stops of the boom, the
spring arm and the adaption.
– Remove any possible collision hazards before swiveling or
height adjustment.
However, if there is still a collision with other devices, wall or
ceiling, the product may be damaged and fail. After a collision,
check the product immediately for possible damage and contact
the operator if necessary.
An individual surgical light is best moved when the boom [4] and
the spring arm [7] form a “V”.
For a light system with several surgical lights, best mobility is
achieved when the extension arms [4] and spring arms [7] form
an “M”.
A collision between the surgical light and adjoining object may lead
to material damage. Observe the operating range of the surgical
light.
If the ALC Plus function is active, the distance to the wound field
will be newly determined when the lamp head is moved. Distance
is measured in an area around the centerline of the light field.
Strongly structured wound fields or other objects in the measuring
range may affect the distance measurement. When moving the
surgical light, care must be taken to ensure that the light field is
aligned with the wound area and that there are no interfering
objects in the measuring range.
Hold the surgical light at the sterile handle [22], the comfort
bracket [12], the 1/4 bracket [13] or light head [14] and move it to
the desired position.
