Technical data
84
7990087_030_03 – 2080492 – 2023-01-19
NOTICE
The iLED 7 surgical light system/Mobile Control 7,9/Wall Control Panel is not designed for use close
to HF surgical equipment. It has been tested in regard to interference immunity exclusively against
radiated fields in the electromagnetic environment set out below, which corresponds to a
professional health care facility.
Immunity levels for HF fields of wireless communications equipment
Table: Special frequencies
Immunity testing EN/IEC 60601-1 test level Compliance level
Conducted HF disturbance
variables in accordance with
EN/IEC 61000-4-6
iLED 7:
3 V
0.15 MHz – 80 MHz
6 V
in the ISM band between 0.15 MHz
and 80 MHz
a)
Mobile Control 7,9:
3 V
0.15 MHz – 80 MHz
6 V
in ISM and amateur radio
frequency bands between
0.15 MHz and 80 MHz
a)+b)
iLED 7:
3 V
0.15 MHz – 80 MHz
6 V
in the ISM band between 0.15 MHz
and 80 MHz
a)
Mobile Control 7,9:
3 V
0.15 MHz – 80 MHz
6 V
in ISM and amateur radio
frequency bands between
0.15 MHz and 80 MHz
a)+b)
Radiated HF disturbance as
per EN/IEC 61000-4-3
iLED 7 System: 3 V/m
Mobile Control 7,9: 10 V/m
80 MHz – 2.7 GHz
iLED 7 System: 3 V/m
Mobile Control 7,9: 10 V/m
80 MHz – 2.7 GHz
a) = The ISM bands (ISM = industrial, scientific and medical) between 0.15 MHz and 80 MHz are
6.765 MHz to 6.795 MHz; 13.553 MHz to 13.567 MHz; 26.957 MHz to 27.283 MHz and 40.66 MHz to
40.70 MHz.
b) = The amateur radio bands between 0.15 MHz and 80 MHz are 1.8 MHz to 2.0 MHz; 3.5 MHz to
4.0 MHz; 5.3 MHz to 5.4 MHz, 7 MHz to 7.3 MHz, 10.1 MHz to 10.15 MHz, 14 MHz to 14.2 MHz, 18.07 MHz
to 18.17 MHz, 21.0 MHz to 21.4 MHz, 24.89 MHz to 24.99 MHz, 28.0 MHz to 29.7 MHz, and 50.0 MHz to
54.0 MHz.
Test
frequency
(MHz)
Band
(MHz)
Service Modulation Max.
power
(W)
Distance
(m)
Immunity
level
(V/m)
385 380–390 TETRA 400 Pulse modulation 15 Hz 1.8 0.3 26
450 430 – 470 GMRS 460
FRS 460
Pulse modulation
FM ± 5 kHz variation
1 kHz sine
20.328
720 704 – 787 LTE band 13, 17 Pulse modulation 217 Hz 0.2 0.3 9
745
780
810 800 – 960 GSM 800/900
TETRA 800
iDEN 820
CDMA 850
LTE band 5
Pulse modulation 18 Hz 2 0.3 28
870
930
