2 – Installation
23
2.2 Instrument Specifications
Physical Dimensions Single Instrument Stack
Height 39.1 cm (15.4 in) 77.5 cm (30.5 in)
Width 67.5 cm (26.6 in) 67.5 cm (26.6 in)
Depth 58.5 cm (23.0 in) 58.5 cm (23.0 in)
Clearance (rear, left, right) 0 cm, 7 cm, 38* cm
* if tablet is mounted
0 cm, 7 cm, 38* cm
* if tablet is mounted
Clearance (front) 61.0 cm (24 in) 61.0 cm (24 in)
Weight (empty) 31.8 kg (70.1 lb) 64.6 kg (142.4 lb)
Weight (full) 38.0 kg (83.7 lb) 76.9 kg (169.6 lb)
Electrical Requirements
Input Voltage 100–240 VAC ± 10%
Peak Current 3 amperes
Input Line Frequency 50/60 Hz
Power 250 W
Heat 307 Btu/hr
Environmental Requirements
Non-Operating Storage
Temperature -17.8 °C – 65 °C (0–149 °F)
Humidity
20–80% RH non-condensing
Operating Conditions
Temperature 18.0–30.0 °C (64.4–86 °F)
Humidity 25–80% RH non-condensing
Locations Level Surface; No direct sunlight; No dir
ect heat or other
external air source; No high humidity, dust, temperature
extremes, or corrosive or explosive vapors or gases
Noise @ 1 m ≤55
dBA using ANSI Type 2 sound meter
Altitude Evaluated for safety to 2,000 m
