BD BACTEC™ FX40 Instrument User’s Manual
30
Select to clear changes and return to saved values. Only active if field values are changed and
are not saved.
Select to save changes. When the Enter Password window appears, select the blank
password field. Enter the Supervisor password with the onscreen keyboard, then select
ENTER, followed by OK.
2.4.2 Reports Configuration
Reports configuration enables you to set up printing and reports parameters. See Figure 2-5.
In a BD EpiCenter™ configuration, modifications made to the Reports configuration settings are used
by all instruments.
Printer Selection Window:
Printer
Select the Drop Down Arrow next to the Printer Selection field to choose the system printer.
Options include:
•No Printer
• Compatible USB Printer (If a BD BACTEC™ FX40 supported printer is connected to the
USB port, its name will appear in the Printer Selection drop-down list.)
Select Save, or Select Undo to clear changes and return to saved values.
QC Auto Report Window:
Time
To set the time for the Maintenance QC Report (Section 5.4.9) to automatically print, select
Set. The default value is 00:00 (midnight) for your time zone. Refer to Section 2.4.5 for
instructions on setting time.
Disable checkbox
To disable automatic printing of the QC Report, select the Disable checkbox. The default
setting is disabled (checked). The checkbox only disables automatic printing; the report can
still be printed by request from the Reports menu.
Custom Fields Window:
Organization 1 / Organization 2
Enter the desired name for your laboratory or hospital. There are two lines of text available,
each of which accepts up to 25 characters. Tap in the Organization 1 field to access the
Save button
NOTE
Incompatible printer may cause system malfunction.
If your printer is not listed, contact BD.
