BD BACTEC™ FX40 Instrument User’s Manual
24
2.3 Instrument Installation
2.3.1 Site Preparation
The BD BACTEC™ FX40 instrument is installed only by BD representatives.
WARNINGS
BECAUSE OF ITS SIZE AND W
EIGHT, TWO PEOPLE SHOULD
LIFT THE BD BACTEC™ FX40 INSTRUMENT.
TIP HAZARD! DO NOT LEAN OR PLACE WEIGHT ON THE
IN
STRUMENT DOOR WHILE IT IS OPEN.
The BD BACTEC™ FX40 instrument should be installed in an area that is free from undue vibration,
dir
ect sunlight, high humidity, dust, temperature extremes, external air sources, and corrosive or
explosive vapors or gases.
The system will operate within spec
ifications in room temperatures from 18.0–30.0 °C (64.4–86.0 °F).
Relative humidity should be between 25–80% (non-condensing) for temperatures less than or equal to
30.0 °C (86.0 °F). The maximum dew point for operation is 26.1 °C for temperatures over 30.0 °C.
No extra clearance is required on the rear of the instru
ment, since the rubber bumpers provide the
needed clearance. A minimum of 7 cm is required on the left side of the instrument for opening the
door, and 38 cm is required on the right for instruments with a tablet mount.
Environments that exceed these limits could adver
sely affect the performance of the system
components.
The incubation system should maintain its temperature to within plus or minus 1.5 °C of the
tem
perature controller's setting (35 °C). This accuracy can be assured only if the room temperature
meets the requirements given above.
Other
Instrument shall withstand thermal decontamination at 65 °C for 10 hours.
The instrument shall withstand paraformaldehyde
treatment as used for mycobacterial
decontamination.
Installation Category II and Pollution Degree 2 as per IEC 664.
Environmental Requirements
