Note:
It is not necessary to remove the winder cover beforehand. When refitting the covers, it’ll be refit last.
Assembly:
• Picture 9 - Replug all power-supplying ribbon cables connecting the touchscreen and PCBA-Front
cover 1, display 2, and EMV 3.
• Picture 10 - Reposition front cover properly, hooking the spring locks into the rear cover. Take care to
properly hook in the front cover at screw g (see pict. 7) and the lug at fastening screw d (see pict. 4).
• Retighten screws g and d.
Important!
The front cover lug for screw c must lie over the rear cover lug. It is necessary to use a
washer along with screw c! Retighten screw and washer.
• Picture 3 - Use a washer along with the front- and rear cover linking fastening screw c at the very
bottom of the machine. Refit and retighten fastening screw and washer.
Disengage feed-dog drop push button, and check if the button sits nicely in the cover opening.
• Picture 5 - Refit and retighten slide-on table anchoring screw (T15) e.
• Picture bottom right in picture 6b - Refit and retighten fastening screw (T10) f left of the bobbin
door.
• Refit lower-thread sensor as outlined in pictures 6, 6a, and 6b.
