2.1 Chamber overview
Figure 4: Overview, closed chamber with single door
Figure 5: Overview, open chamber with single door
(1) Triangular instrument panel with MB2 controller and USB interface
(2) Door handle
(3) Outer door
(4) On/Off switch (up to size 115), with M 260 cover without function
(5) Rack
