Output Conguration 37
CH1 + CH2
Operation mode will be set to Series 1 + 2. Changing operation mode will undo previous coupling
conguration.
Press the button then use the soft key to select Output Cong > Op. Mode/Coupling > Operation
Mode > Series > CH1 + CH2.
Figure 4.5 Series 1+2
In Series CH1 + 2 the main page will display the output of the combined outputs, as well as the output
of the individual CH3. The button will toggle through single channel display for Series CH1 + 2,
CH 3, and live output monitoring.
Figure 4.6 Series CH1+2 Main Page
