Group ID Parameter Type Index Minimum Maximum Interpretation
Display
4.0 Brightness fixed16 – 0.0 1.0 0.0 = minimum, 1.0 = maximum
4.1
Exposure and focus tools
uint16
bit field
[0] = bit field – –
bit flags:
[0] = Zebra
[1] = Focus Assist
[2] = False Color
uint16
bit field
[1] = target displays
bit field
– –
bit flags:
[0] = LCD
[1] = HDMI
[2] = EVF
[3] = Main SDI
[4] = Front SDI
4.2 Zebra level fixed16 – 0.0 1.0 0.0 = minimum, 1.0 = maximum
4.3 Peaking level fixed16 – 0.0 1.0 0.0 = minimum, 1.0 = maximum
4.4 Color bar enable int8 – 0 30
0 = disable bars,
1-30 = enable bars with timeout
(seconds)
4.5 Focus Assist int8
[0] = focus assist
method
– –
0 = Peak,
1 = Colored lines
[1] = focus line color – –
0 = Red,
1 = Green,
2 = Blue,
3 = White,
4 = Black
4.6 Program return feed enable int8 – 0 30
0 = disable, 1-30 = enable with
timeout (seconds)
4.7 Timecode Source
signed
byte
[0] = source – –
0 = Clip,
1 = Timecode
Tally
5.0 Tally brightness fixed16 – 0.0 1.0
Sets the tally front and tally rear
brightness to the same level.
0.0 = minimum,
1.0 = maximum
5.1 Front tally brightness fixed16 – 0.0 1.0
Sets the tally front brightness.
0.0 = minimum,
1.0 = maximum
5.2 Rear tally brightness fixed16 – 0.0 1.0
Sets the tally rear brightness.
0.0 = minimum,
1.0 = maximum
Tally rear brightness cannot be
turned off
Reference
6.0 Source int8 enum – 0 2
0 = internal,
1 = program,
2 = external
6.1 Offset int32 – – – +/- offset in pixels
400Developer Information
