Local/Remote 412 Function
0 -
Control via
Contacts
The Start and Stop commands as well as the direction of
rotation are controlled via digital signals.
1 -
Control via
Statemachine
The Start and Stop commands as well as the direction of
rotation are controlled via the DRIVECOM State machine
of the communication interface.
2 -
Control via
remote contacts
The Start and Stop commands as well as the direction of
rotation are controlled via logic signals through the
communication protocol.
3 -
Control via Keypad,
direction of rot. via
contacts
The Start and Stop commands are controlled from the
control unit and the direction of rotation is controlled via
digital signals.
4 -
Cont. via KP or Cont.,
direction of rot. via
cont.
The Start and Stop commands are controlled from the
control unit or via digital signals. The direction of rota-
tion is controlled via digital signals only.
5 -
Ctrl. 3-Wire, direction
Cont.
3-wire; control of direction of rotation and signal
3-Wire Control 87 via contacts.
13 -
Control via KP,
direction of rot. via
KP
The Start and Stop commands as well as the direction of
rotation are controlled via the control unit.
14 -
Control via KP +
cont.,
direction of rot. via
contact
The Start and Stop commands are controlled from the
control unit or via digital signals. The direction of rota-
tion is controlled via the control unit only.
20 -
Control via contacts,
clockwise rot. only
The Start and Stop commands are controlled via digital
signals. Fixed direction of rotation, clockwise rotation
only.
23 -
Control via keypad,
clockwise rot. only
The start and stop commands are controlled via keypad.
Fixed direction of rotation, clockwise rotation only.
24 -
Control via cont. +KP,
clockwise rot. only
The Start and Stop commands are controlled from the
control unit or via digital signals. Fixed direction of rota-
tion, clockwise rotation only.
30 to 34
Operation mode 20 to 24, anticlockwise direction of ro-
tation only.
43 -
Control via KP,
direction of rot. via
contact + KP
The start and stop commands are controlled via digital
signals. The direction of rotation is controlled from the
control unit or via digital signals.
44 -
Control via cont.+ KP,
direction of rot. via
cont. + KP
Both the Start and Stop commands as well as the sense
of rotation can be controlled from either the control unit
or via digital signals.
46 -
Ctrl. 3-Wire + KP, Dir.
Cont. + KP
3-wire and control unit; control of direction of rotation
and signal
3-Wire Control 87 via contacts or control unit.
