Item Location Default New Item Location Default New
Polarity 0744 0 Polarity 0750 0
Time Base 0745 0 Time Base 0751 0
Time Base Multiplier 0746 0 Time Base Multiplier 0752 0
Time Base Multiplier 0747 0 Time Base Multiplier 0753 0
For output item options, refer to below Output Item Options.
Item Option
B228 Output Mode 0 = Not used
1 = Aux power
2 = Switched negative
4 = Open collector
Event Code 0 0 = Reserved
0 1 = System armed
0 2 = System disarmed
0 3 = Armed in STAY mode
0 4 = Armed in AWAY mode
0 5 = Pre-arming alert
0 6 = Exit Warning (all zones sealed) and
entry warning
0 7 = Exit Warning
0 8 = Exit Warning finished
0 9 = Kiss-off after end of Exit Time
0 10 = Reserved
0 11 = Entry warning
0 12 = Entry warning and day alarm resetting
0 13 = Exit warning and entry warning and
day alarm resetting
0 14 = Day alarm resetting
0 15 = Day alarm latching
1 0 = Day alarm enabled
1 1 = Telephone line fail
1 2 = Kiss-off received
1 3 = AUX Power Supply fail
1 4 = AC fail
1 5 = Low battery
1 6 = Output 1 fail
1 7 = Sensor watch alarm
1 8 = Codepad medical alarm
1 9 = Codepad fire alarm
1 10 = Codepad panic alarm
1 11 = Codepad duress alarm
1 12 = Access denied (code retries)
1 13 = Reserved
1 14 = Horn speaker (output 1 only)
1 15 = Siren running
Event Code
2 0 = Strobe
2 1 = Silent alarm
2 2 = Alarm in STAY mode
2 3 = Alarm in AWAY mode
2 4 = System fault
2 5 = Fire alarm (resetting)
2 6 = Fire alarm (latching)
2 7 = Fire alarm (verification)
2 8 = Remote control 1
2 9 = Remote control 2
2 10 = Remote control 3
2 11 = Radio control output 1
2 12 = Radio control output 2
2 13 = Radio control output 1- not in AWAY
Mode
2 14 = Radio control output 2- not in AWAY
Mode
2 15 = Communications fail after 3 attempts
3 0 = Communications fail
3 1 = Report disabled
3 2 = Report active (on-line)
3 3 = Ring detect
3 4 = Codepad/Keyfob panic
3 5 = Mimic zone 1
3 6 = Mimic zone 2
3 7 = Mimic zone 3
3 8 = Mimic zone 4
3 9 = Mimic zone 5
3 10 = Mimic zone 6
3 11 = Mimic zone 7
3 12 = Mimic zone 8
3 13 = Mimic zone 9
3 14 = Mimic zone 10
3 15 = Mimic zone 11
Control Panel Programmable Outputs | en 121
Bosch Security Systems, Inc. Installation Guide 2017.10 | 03 | F.01U.298.026
