Item Option
Event Code 4 0 = Mimic zone 12
4 1 = Mimic zone 13
4 2 = Mimic zone 14
4 3 = Mimic zone 15
4 4 = Mimic zone 16
4 5 = Chime
4 6 = Zone not sealed
4 7 = Zone not sealed after Exit Time
4 8 = Reserved
4 9 = AC MAINS cycle (60 Hz or 50 Hz)
4 10 = Area 1 – zone unsealed
4 11 = Area 2 – zone unsealed
4 12 = Reserved
4 13 = Reserved
4 14 = Reserved
4 15 = Reserved
5 0 = Reserved
5 1 = Reserved
5 2 = Area 1 in alarm
5 3 = Area 2 in alarm
5 4 = Reserved
5 5 = Reserved
5 6 = Area 1 armed
5 7 = Area 2 armed
5 8 = Reserved
5 9 = Reserved
5 10 = Area 1 disarmed
5 11 = Area 2 disarmed
5 12 = Reserved
5 13 = Reserved
5 14 = Any areas armed
5 15 = Any areas disarmed
Event Code
6 0 = Reserved
6 1 = Reserved
6 2 = Remote control 4
6 3 = Remote control 5
6 4 = Remote control 6
6 5 = Remote control 7
6 6 = Remote control 8
6 7 = Remote control 9
6 8 = Remote control 10
6 9 = Remote control 11
6 10 = Remote control 12
6 11 = Remote control 13
6 12 = Remote control 14
6 13 = Remote control 15
6 14 = Remote control 16
6 15 = Remote control 17
7 0 = Remote control 18
7 1 = Remote control 19
7 2 = Remote control 20
7 3 = Remote control 21
7 4 = Remote control 22
Polarity (Modes)
0 = Output not used
1 = Normally open, going low
2 = Normally open, pulsing low
3 = Normally open, one shot low
4 = Normally open, one shot low (reactivate)
5 = Normally open, one shot low (can reset)
6 = Normally open, one shot low (alarm)
7 = Normally open, latching low
8 = Normally low, going open
9 = Normally low, pulsing open
10 = Normally low, one shot open
11 = Normally low, one shot open
(reactivate)
12 = Normally low, one shot open (can
reset)
13 = Normally low, one shot open (alarm)
14 = Normally low, latching open
Time Base 0 = Reserved
1 = 200 ms
2 = 1 sec.
3 = 1 min.
4 = 1 hr.
Time Base Multiplier Enter a value between 00 and 99.
Table 16.2: Output Item Options
* One Shot Mode
When you program the output polarity as one shot, the time base is multiplied by the time
base multiplier. (For example, if the time base = 2 and the multiplier = 05, the output operates
for 5 sec.)
122 en | Programmable Outputs Control Panel
2017.10 | 03 | F.01U.298.026 Installation Guide Bosch Security Systems, Inc.
