Item Location Default New Item Location Default New
Zone 11 Area 0512 1 Zone 12 Area 0513 1
Zone 13 Area 0514 1 Zone 14 Area 0515 1
Zone 15 Area 0516 1 Zone 16 Area 0517 1
Option
0 = Zone area not assigned
1 = Zone assigned to Area 1
2 = Zone assigned to Area 2
3 = Zone assigned to both Area 1 and Area 2
Example
Program Location 502 as 3, Location 503-509 as 1 , Location 510-517 as 2, Zones 1-8 are
allocated to Area 1 to appear as zones 1-8. Zones 1, 9-16 are allocated to Area 2 to appear as
zones 1, 9-16. In each area’s codepad, zone’s original No is displayed. In this example, If
Zone16 is activated, in Area 2’s ICON codepad, Zone 16 indicator lights. Programming the
same zone into more than one area specifies that zone as a common zone.
Wireless zones and wired zones can share the same zone numbers. When the wireless zones
are enables, the wired zones allocated to the same numbers cannot respond anymore.
See also
– Zone Programming, page 93
– RF Device RFID, page 109
Codepad assignment
Item Location Default New Item Location Default New
Codepad 1 Area 0518 1 Codepad 2 Area 0519 0
Codepad 3 Area 0520 0 Codepad 4 Area 0521 0
Option
0 = Codepad area not assigned
1 = Codepad assigned to Area 1
2 = Codepad assigned to Area 2
3 = Codepad assigned to both Area 1 and Area 2
Any codepad can be assigned to any area or both areas with a partitioned Control Panel.
User code area assignments
Item Location Default New Item Location Default New
User Code 1 0534 1 User Code 2 0535 1
User Code 3 0536 1 User Code 4 0537 1
User Code 5 0538 1 User Code 6 0539 1
User Code 7 0540 1 User Code 8 0541 1
User Code 9 0542 1 User Code 10 0543 1
User Code 11 0544 1 User Code 12 0545 1
User Code 13 0546 1 User Code 14 0547 1
User Code 15 0548 1 User Code 16 0549 1
