83
Section 3. Using effects
Section 3
Hi Ratio 1:1.00 – 1:16.0, 1:INF
This sets the ratio of suppression of the upper-
range output when the input level exceeds the Hi
threshold level.
Hi Attack 0 – 100 ms
This sets the time it takes for the upper-range
compressor to go into effect once the input level
exceeds the Hi threshold level.
Hi Release 50 – 5000 ms
This sets the time it takes for the upper-range
compressor effect to stop once the input level
falls below the Hi threshold level.
This divides the original sound into three
frequency ranges: low, mid, and high.
Gain -24 – +12 dB
Sets the overall volume level before the signal
passes through the compressor.
Dly Time 0–10 ms
This sets the amount of time by which the source
input sound is delayed.
SplitL 20 – 800 Hz
This sets the frequency (in the lower range) at
which the source sound is split into three
separate ranges.
SplitH 1.6 – 16.0 kHz
This sets the frequency (in the upper range) at
which the source sound is split into three
separate ranges.
This suppresses high-level signals to prevent
distortion.
On/Off OFF, ON
Sets the limiter to ON or OFF.
Threshold -24 – 0 dB
Adjust this parameter to match the signal.
Limiting will be applied to input levels in excess
of this level.
Attack 0 – 100 ms
This sets the time it takes for the limiter to go into
effect once the input level exceeds the threshold
level.
Release 50 – 5000 ms
Adjusts the time until when the limiter will turn
off after the input level falls below the threshold
level.
Adjusts the volume of each frequency band.
Lo Level -80 – +6 dB
Sets the volume level of the lower range after the
signal passes through the compressor.
Mid Level -80 – +6 dB
Sets the volume level of the midrange after the
signal passes through the compressor.
Hi Level -80 – +6 dB
Sets the volume level of the upper range after the
signal passes through the compressor.
This makes settings that affect the overall output.
Level -80 – +6 dB
Sets the volume level of the overall sound after
the signal passes through the limiter.
INPUT
With the compressor, the level is
automatically adjusted to the optimum
setting according to the threshold
(Threshold) and ratio (Ratio) settings. In
addition, since lengthening the attack
(Attack) setting may result in distortion, a
buffer (margin) of -6 dB is provided. Adjust
the Mixer level as needed.
LIMITER
MIXER
OUTPUT
