Section 3. Using effects
The algorithms (the available effects and their
connection order) that can be used as the insert
effects are shown below.
The algorithms that can be selected will differ for
each bank. To select the algorithm that you wish
to use, first select the effect bank that includes
that algorithm, and then refer to “Effect Patch
List” (Leaflet) and select a patch that uses the
desired algorithm.
This is a multi-effect designed for electric guitar.
This provides an amp sound using a preamp and
speaker simulator.
* In case of “Phaser,” output will become monaural.
fig.03-170
PREAMP
SPEAKER SIM
NOISE SUPPRESSR
FX
- COMPRESSOR
- CHORUS
- FLANGER
- PHASER
- TREMOLO/PAN
DELAY
This is a multi-effect designed for vocals.
It provides the basic effects needed for vocals.
3BAND COMP
ENHANCER
4BAND EQ
NOISE SUPPRESSR
DELAY
These effects are for stereo line input or an
external mic.
The LINE/EXT bank uses the same effects as the
mastering tool kit.
However, the effect parameters are saved
individually in each bank.
INPUT
3BAND COMP
MIXER
LIMITER
OUTPUT
Insert Effects Algorithm List
• The line or lines connecting the algorithm indicate whether the effect features mono output (single line)
or stereo output (two lines).
(Ex.)
–[
AMP
]–[
SP
]–
=[
LIM
]=[
OUT
]=
Output: Stereo
Output: Mono
GT (Guitar) Bank [COSM GTR AMP]
–[AMP]–[SP]–[NS]–[FX]–[DLY]=
MC (Mic) Bank [VOCAL MULTI]
–[CMP]–[ENH]–[EQ]–[NS]–[DLY]=
LN/EX (Line/External Mic) Bank [MSTR TOOL KIT]
=[IN]=[CMP]=[MIX]=[LIM]=[OUT]=
