Getting ready to use the MICRO BR
Make connections as shown in the following
diagram.
Your equipment must be powered off when
making connections.
fig.side-panel-L.eps
fig.side-panel-R.eps
Plug-in powered microphone (p. 19)
Connecting other equipment
Headphones
Computer
AC Adaptor
(PSA series)
Side Panel (Left)
Electric Guitar
Electric Bass
Dynamic Mic or
Plug-in powered
Condenser Mic
CD/MD
Player etc.
Side Panel (Right)
