Brother E850TKW - Inside

Setting Up the P-touch
3
1
11 (Feed and Cut) button
12 (Wi-Fi) button
13 Keyboard LCD unit
14 Keyboard LCD unit interface socket
15 Cable holder (holder for the keyboard LCD unit cable)
16 USB port
17 AC adapter socket
Inside 1
1 Tube release lever
2 Tube half-cut adjuster
3 Tube cutter board
4 Tube cutter
5 Tube exit slot
6 Platen roller
7 Print head (for tube)
8 Coin cell battery holder
9 Ribbon cassette compartment (for tube)
10 Tape exit slot
11 Tube cleaner
12 Tube insert slot
13 Tape cassette compartment
14 Print head (for tape)
15 Tape cutter unit
1
9
6
7
10
11
14
13
15
12
8
234
5
