Brother MFC-L2700D Service Manual

2-98
Confidential
4.14.3 Machine is not turned ON
<User Check>
- Check that the power cord is inserted into the terminal correctly.
- Turn the power off and on.
Step Cause Remedy
1
Rubber key attachment failure
(For models without touch panel)
Reattach the rubber key.
2
Connection failure of panel harness Reconnect the panel harness.
3
Connection failure of key PCB flat
cable (For models with touch panel)
Reconnect the key PCB flat cable.
4
Connection failure of LCD flat cable Reconnect the LCD flat cable.
5
Connection failure of LVPS harness Reconnect the LVPS harness.
6
Power cord failure Replace the power cord.
7
Panel PCB failure Replace the panel PCB.
8
LCD failure Replace the LCD.
9
Low-voltage power supply PCB
failure
Replace the low-voltage power supply PCB
ASSY.
10
Main PCB failure Replace the main PCB ASSY.

Brother MFC-L2700D Specifications

General

Print Technology	Laser
Print Resolution	Up to 2400 x 600 dpi
Duplex Printing	Yes
Paper Input Capacity	250 sheets
Monthly Duty Cycle	Up to 10, 000 pages
Functions	Print, Copy, Scan, Fax
ADF Capacity	35 sheets
Memory	32 MB
Fax Speed	33.6 Kbps
Print Speed	Up to 27 ppm
Connectivity	USB 2.0
Scanner Type	Flatbed
Copy Speed	Up to 27 cpm
Scan Resolution	Up to 600 x 2400 dpi
Display	2-line LCD
