Brother MFC-L2700D Service Manual

5-5
Confidential
1.3.2 Print white level / black level data for document scanning
compensation (function code: 05)
<Function>
This function is used to print the contrast level data for document scanning compensation.
<Operating Procedure>
Note:
• Be sure not to perform this operation procedure immediately after the power is turned
ON, but after performing the document scanning operation at least once. The machine
initializes the contrast level data and obtains the standard value for document scanning
compensation at the start of the document scanning. Therefore, this function is
inoperable without performing a document scanning operation first.
• The print result varies depending on whether color scanning or monochrome scanning
is performed immediately before this operation procedure. Check the contrast level data
you want to print and then implement the procedure below.
For models without keypad
(1) For monochrome scanning, make a
monochrome copy of the document. For
color scanning, make a color copy of the
document.
(2) Press the [▲] or [▼] key in the initial
state of maintenance mode to display
"MAINTENANCE 05" on the LCD, and
press the [OK] key.
"PRINTING" is displayed on the LCD,
and the data list for document scanning
compensation including the following
data will be printed.
(3) When printing is completed, the
machine returns to the initial state of
maintenance mode.
For models with keypad
(1) For monochrome scanning, make a
monochrome copy of the document. For
color scanning, make a color copy of the
document.
(2) Press the [0], and then the [5] key in the
initial state of maintenance mode. "1.
FRONT 2. BACK" is displayed on the
LCD. (Duplex scanning models only)
(3) Press the [1] or [2] key. "PRINTING" is
displayed on the LCD, and the data list
for document scanning compensation
including the following data will be
printed.
(4) When printing is completed, the
machine returns to the initial state of
maintenance mode.
Note:
• When there is no paper set in the
paper tray, printing will be
canceled.
Note:
• When there is no paper set in the
paper tray, printing will be
canceled.

Brother MFC-L2700D Specifications

General

Print Technology	Laser
Print Resolution	Up to 2400 x 600 dpi
Duplex Printing	Yes
Paper Input Capacity	250 sheets
Monthly Duty Cycle	Up to 10, 000 pages
Functions	Print, Copy, Scan, Fax
ADF Capacity	35 sheets
Memory	32 MB
Fax Speed	33.6 Kbps
Print Speed	Up to 27 ppm
Connectivity	USB 2.0
Scanner Type	Flatbed
Copy Speed	Up to 27 cpm
Scan Resolution	Up to 600 x 2400 dpi
Display	2-line LCD
