Brother MFC-L2700D Service Manual

3-4
Confidential
4. SCREW TORQUE LIST
Location of screw Screw type Q’ty
Tightening torque
N·m (kgf·cm)
Cord hook Taptite cup B M3x8 2 0.40.05 (40.5)
Side cover R Taptite bind B M4x12 1 0.80.1 (81)
Inner chute ASSY Taptite bind B M4x12 2 0.80.1 (81)
Side cover L Taptite bind B M4x12 1 0.80.1 (81)
Handset holder ASSY Taptite bind B M4x12 2 0.80.1 (81)
Upper handset holder Taptite cup B M3x8 1 0.50.1 (51)
Document scanner FG harness Taptite cup S M3x8 SR 1 0.50.05 (50.5)
ADF FG harness
(Main shield plate side)
Taptite cup S M3x8 SR
1
0.50.05 (50.5)
ADF FG harness
(Lower chute support plate side)
Taptite cup S M3x8 SR
1
0.70.1 (71)
Hinge ASSY L
(For models with ADF)
Taptite bind B M4x12 1 0.80.1 (81)
Taptite cup S M3x12 3 0.80.1 (81)
Hinge R support
(For models with ADF)
Taptite cup B M3x10
1
0.50.05 (50.5)
Hinge arm R (For models with ADF) Taptite cup B M3x10 3 0.50.05 (50.5)
ADF front cover Taptite cup B M3x10 2 0.50.05 (50.5)
Upper document chute ASSY Taptite cup B M3x10 4 0.50.05 (50.5)
Lower document chute ASSY Taptite cup B M3x10 3 0.50.05 (50.5)
Drive frame ASSY Taptite cup B M3x10 3 0.5
0.05
(50.5)
ADF motor Screw pan (S/P washer)
M3x6
1
0.350.05
(3.50.5)
Hinge L support
(For models without ADF)
Taptite cup B M3x10
1
0.50.05 (50.5)
Hinge R support
(For models without ADF)
Taptite cup B M3x10
1
0.50.05 (50.5)
Hinge arm L
(For models without ADF)
Taptite cup B M3x10
3
0.50.05 (50.5)
Hinge arm R
(For models without ADF)
Taptite cup B M3x10
3
0.50.05 (50.5)
Panel unit Taptite cup B M3x10 4 0.50.05 (50.5)
Shield plate cover Taptite cup B M3x10 4 0.50.05 (50.5)
Panel key PCB presser Taptite cup B M3x10 2 0.50.05 (50.5)
Document scanner top cover Taptite bind B M4x12 6 0.80.1 (81)
Modem FG harness LVPS Screw pan (S/P washer)
M3.5x6
2
0.60.1 (61)
Modem FG harness main Screw pan (S/P washer)
M3.5x6
1
0.60.1 (61)
Taptite cup S M3x8 SR 1 0.50.1 (51)
Modem shield plate Taptite bind B M4x12 2 0.80.1 (81)

Brother MFC-L2700D Specifications

General

Print Technology	Laser
Print Resolution	Up to 2400 x 600 dpi
Duplex Printing	Yes
Paper Input Capacity	250 sheets
Monthly Duty Cycle	Up to 10, 000 pages
Functions	Print, Copy, Scan, Fax
ADF Capacity	35 sheets
Memory	32 MB
Fax Speed	33.6 Kbps
Print Speed	Up to 27 ppm
Connectivity	USB 2.0
Scanner Type	Flatbed
Copy Speed	Up to 27 cpm
Scan Resolution	Up to 600 x 2400 dpi
Display	2-line LCD
