1.2 List of Maintenance Mode Functions
* The maintenance mode functions shaded in the table can be used by end users.
Function
code
Function Refer to:
01 Initialize EEPROM parameters 1.3.1
05
Print white level / black level data for document scanning
compensation
1.3.2
08 ADF performance test 1.3.3
09 Monochrome print quality test pattern 1.3.4
10 Set worker switches (WSW) 1.3.5
11 Print worker switch (WSW) setting data 1.3.5
12 Check LCD operation 1.3.6
13 Check control panel operation 1.3.7
25 Display software version 1.3.8
28 Change OnePushDemo function setting 1.3.9
32 Check sensor operation 1.3.10
33 Display LAN connection status 1.3.11
43 Set PC print functions 1.3.12
45
Change USB No. return value / Adjust left-end print start
position on second side when duplex printing
1.3.13
52 Set country / language 1.3.14
53 Transfer received fax data / log information 1.3.15
54 Fine-tune scanning position 1.3.16
55 Acquire white level data and set CIS scan area 1.3.17
61 Adjust touch panel 1.3.18
67 Continuous print test 1.3.19
69 Print frame pattern (single-side printing) 1.3.20
70 Print frame pattern (duplex printing) 1.3.21
71 Test pattern 1.3.22
74 Setting by spec 1.3.23
77 Print maintenance information 1.3.24
78 Check fan operation 1.3.25
80 Display machine log information 1.3.26
82 Display machine error code 1.3.27
87 Send communication log information to telephone line 1.3.28
88
Reset irregular power supply detection counter of low-
voltage power supply PCB
1.3.29
91 Initialize EEPROM parameters 1.3.1
99 Quit maintenance mode 1.3.30

Brother MFC-L2700D Specifications

General

Print Technology	Laser
Print Resolution	Up to 2400 x 600 dpi
Duplex Printing	Yes
Paper Input Capacity	250 sheets
Monthly Duty Cycle	Up to 10, 000 pages
Functions	Print, Copy, Scan, Fax
ADF Capacity	35 sheets
Memory	32 MB
Fax Speed	33.6 Kbps
Print Speed	Up to 27 ppm
Connectivity	USB 2.0
Scanner Type	Flatbed
Copy Speed	Up to 27 cpm
Scan Resolution	Up to 600 x 2400 dpi
Display	2-line LCD
