3-3

Confidential

3. SCREW CATALOGUE

Fig. 3-2

Taptite cup S

Taptite pan B

Screw pan (S/P washer)

Taptite pan B

M4x14

Screw pan (S/P washer)

M3x12DB

Taptite cup S

M3x12

Taptite cup S

M3x8 SR

Screw bind

M3x4

Screw pan (S/P washer)

M3.5x6

Taptite bind B

M3x10

Taptite bind B

M4x12

Taptite cup S

M3x6 SR

Taptite cup B

M3x8

Taptite cup B

M3x10

Screw pan (S/P washer)

M3x6

Taptite flat B

M3x10
