Brother MFC-L2700D Service Manual

5-17
Confidential
1.3.10 Check sensor operation (function code: 32)
<Function>
This function is used to check that sensors are operating normally.
<Operating Procedure>
The table below summarizes the displays on the LCD, sensor names and detection status.
Common to models without/with keypad
(3) Change the conditions subject to sensor detection and check that the display on the
LCD changes depending on the sensor status. For example, feed the paper through the
registration front/rear sensor, open the front cover or back cover, remove the toner
cartridge, or create paper jam at the exit.
(4) When you press the [X] or [Stop] key, this operation is finished and the machine returns
to the initial state of maintenance mode.
LCD Sensor names
Detection status
(displayed / not displayed)
C1
NT
CV
RC
PO
RM
RA
Paper feed sensor
New toner sensor
Front cover sensor
Back cover/duplex tray sensor
Eject sensor
Registration front sensor
Registration rear sensor
Paper tray set / No paper tray
Toner cartridge set / No toner cartridge
Front cover closed / Front cover open
Back cover closed with duplex tray set /
Back cover open or no duplex tray
No paper / Paper set
No paper / Paper set
No paper / Paper set
MAC XXC Internal temperature thermistor XX°C / NG
DF
DR
AC
DB
Document detection sensor
First side document scanning
position sensor
ADF cover sensor
Second side document scanning
position sensor
No document / Document set
No document / Document set
ADF cover closed / ADF cover open
No document / Document set
For models without keypad
(1) Press the [▲] or [▼] key in the initial
state of maintenance mode to display
"MAINTENANCE 32" on the LCD, and
press the [OK] key.
"C1NTCVRCPORMRA" is displayed on
the LCD.
(2) Pressing the [Start] key changes the
display to the next item.
For models with keypad
(1) Press the [3], and then the [2] key in the
initial state of maintenance mode.
"C1NTCVRCPORMRA" is displayed on
the LCD.
400Hz OFF, 400Hz S, 400Hz M, 400Hz
L, 1100Hz OFF, 1100Hz S, 1100Hz M,
1100Hz L tones ring continuously to test
the speaker.
(2) Pressing the [Start] or [Mono Start] key
changes the display to the next item.
Note:
• Press the [SET] or [Menu] key to
stop the tones.

Brother MFC-L2700D Specifications

General

Print Technology	Laser
Print Resolution	Up to 2400 x 600 dpi
Duplex Printing	Yes
Paper Input Capacity	250 sheets
Monthly Duty Cycle	Up to 10, 000 pages
Functions	Print, Copy, Scan, Fax
ADF Capacity	35 sheets
Memory	32 MB
Fax Speed	33.6 Kbps
Print Speed	Up to 27 ppm
Connectivity	USB 2.0
Scanner Type	Flatbed
Copy Speed	Up to 27 cpm
Scan Resolution	Up to 600 x 2400 dpi
Display	2-line LCD
