4-2
Confidential
1.1 Setting by Spec (Function code: 74)
Configure the setting by spec as described in “1.3.23 Setting by spec (function code: 74)” in
Chapter 5.
1.2 Installing Firmware (Sub firmware, demo firmware,
panel firmware, and main firmware)
1.2.1 Checking firmware version
Check whether the firmware installed on the machine is the latest version. If it is the latest
version, there is no need to install the firmware. If it is not, be sure to install the firmware to
the machine as described in “1.2.2 Installing firmware”.
<How to check firmware version>
For models without touch panel
(1) Press the [Menu], and then the [Start]
key while the machine is in the ready
state. Then, press the [▲] key four
times to enter the maintenance mode.
(2) Press the [▲] or [▼] key to display
"MAINTENANCE 25" on the LCD, and
press the [OK] key. For keypad
models, press the [2] and [5] keys in
this order. The main firmware version
information is displayed on the LCD.
(3) Press the [Start] key to display the
version information of the sub
firmware and demo firmware on the
LCD, and then check the version
information.
For models with touch panel
(1) Press and hold the [Home] key for
approximately five seconds while the
machine is in the ready state.
(2) Press and hold the blank field at the
bottom of the LCD for approximately
two seconds.
(3) Press the [*], [2], [8], [6], and [4] keys
on the LCD in this order to enter the
maintenance mode.
(4) Press the [2] and [5] keys in this order.
The main firmware version information
is displayed on the LCD.
(5) Press the [Mono Start] key to display
the version information of the sub
firmware, demo firmware, and panel
firmware on the LCD, and then check
the version information.
Note:
• You can check the sub firmware, demo firmware, panel firmware, and main firmware
version by implementing "Print maintenance information (function code: 77)"
(refer to “1.3.24 Print maintenance information (function code: 77)” in Chapter 5).
To Next Page
