Brother MFC-L2700D Service Manual

5-6
Confidential
 Data to be printed (common to monochrome / color)
a) LED CURRENT 1 Byte
b) LED pulse data1 (UP) (G) 2 Byte
c) LED pulse data1 (DOWN) (G) 2 Byte
d) LED pulse data1 (UP) (B) 2 Byte
e) LED pulse data1 (DOWN) (B) 2 Byte
f) LED pulse data1 (UP) (R) 2 Byte
g) LED pulse data1 (DOWN) (R) 2 Byte
h) LED pulse data2 (UP) (G) 2 Byte
i) LED pulse data2 (DOWN) (G) 2 Byte
j) LED pulse data2 (UP) (B) 2 Byte
k) LED pulse data2 (DOWN) (B) 2 Byte
l) LED pulse data2 (UP) (R) 2 Byte
m) LED pulse data2 (DOWN) (R) 2 Byte
n) VCOM DATA 2 Byte
o) Background color compensation data 1 Byte
p) GAIN adjustment black Level MAX Data (300 dpi SX) 2 Byte
q) GAIN adjustment black Level MAX Data (600 dpi SX) 2 Byte
r) GAIN adjustment black Level MAX Data (300 dpi DX first side) 2 Byte
*1
s) GAIN adjustment black Level MAX Data (600 dpi DX first side) 2 Byte
*1
t) GAIN adjustment black Level MAX Data (300 dpi DX second side) 2 Byte
*1
u) GAIN adjustment black Level MAX Data (600 dpi DX second side) 2 Byte
*1
v) HP detection black compensation data 2 Byte x 12
w) Black level data Based on previous scanning pixel count
x) White level data (G) Based on previous scanning pixel count
y) White level data (B) Based on previous scanning pixel count
z) White level data (R) Based on previous scanning pixel count
*1
Displayed on duplex models only
 Common to first / second side
Fig. 5-1

Brother MFC-L2700D Specifications

General

Print Technology	Laser
Print Resolution	Up to 2400 x 600 dpi
Duplex Printing	Yes
Paper Input Capacity	250 sheets
Monthly Duty Cycle	Up to 10, 000 pages
Functions	Print, Copy, Scan, Fax
ADF Capacity	35 sheets
Memory	32 MB
Fax Speed	33.6 Kbps
Print Speed	Up to 27 ppm
Connectivity	USB 2.0
Scanner Type	Flatbed
Copy Speed	Up to 27 cpm
Scan Resolution	Up to 600 x 2400 dpi
Display	2-line LCD
