Brother MFC-L2700D Service Manual

5-46
Confidential
*1
Models with touch panel only
*2
Models with modem only
1 Model name 28 Total printed pages
2 Serial number 29 Copied pages
3 Model code 30 Printed PC pages
4 Country code 31 List/Fax pages
5 Switch check sum (factory use) 32 Accumulated average coverage
6
Main firmware version
33
Average coverage by the current toner
cartridge
7
Sub firmware version
34
Average coverage by the previous toner
cartridge
8 Boot firmware version 35 Drum page count
9 Demo firmware version 36 Rotations of the drum
10
Engine firmware version
37
Total rotations of the developer roller
(currently / previously used toner)
11
Panel firmware version
*1
38
Total printed pages per paper tray / paper
size / paper type
12 Panel boot firmware version
*1
39 Printed pages per current toner cartridge
13
Memory version
40
Printed pages per previously used toner
cartridge
14
ROM check sum
*2
41
Total rotations of the developer roller
excluding rotations not related to printing
such as warming-up (currently / previously
used toner)
15 RTC (Real Time Clock) check
*2
42 Total paper jams / Paper jams by section
16
RTC (Real Time Clock) backup
*2
43
Machine error log / Total pages printed at the
time of the error
17
Time before RTC (Real Time Clock) backup
*2
44
Replacement count by consumables and
periodic replacement parts
18 Time after RTC (Real Time Clock) backup
*2
45 Scanned pages
19 USB ID code 46 Communication error log
*2
20 RAM size 47 Developing bias voltage value
21
Function code: 55 result / Wireless LAN
setting by spec / Wireless LAN output peak /
WLAN Setup YES/NO setting / Current toner
cartridge type / Previous toner cartridge type
48
Engine sensor log (Not necessary for
maintenance)
22
Main PCB inspection log / High voltage
inspection log / The number of times that the
discharge error / Fuser unit error / Polygon
motor lock error / Irregular power supply
detection error occurred / Process status /
Next power on state
49
Status log (Not necessary for maintenance)
23
Process status / Process checksum
50
Home position detection error / Home
position detection error log (Not necessary
for maintenance)
24
Not necessary for maintenance (ADF sensor
log)
51
Total power distribution time
25
Estimated remaining toner amount
52
The number of times that the power is turned
ON
26
Remaining life of drum unit
53
Start date for machine operation / First RTC
setting date
27
Threshold setting rate when toner is running
out

Brother MFC-L2700D Specifications

General

Print Technology	Laser
Print Resolution	Up to 2400 x 600 dpi
Duplex Printing	Yes
Paper Input Capacity	250 sheets
Monthly Duty Cycle	Up to 10, 000 pages
Functions	Print, Copy, Scan, Fax
ADF Capacity	35 sheets
Memory	32 MB
Fax Speed	33.6 Kbps
Print Speed	Up to 27 ppm
Connectivity	USB 2.0
Scanner Type	Flatbed
Copy Speed	Up to 27 cpm
Scan Resolution	Up to 600 x 2400 dpi
Display	2-line LCD
