Brother MFC-L2700D Service Manual

2-47
Confidential
 Error code 8903
The back cover/duplex tray sensor detected that the cover was open when duplex printing is
started. (Before registering printing data to engine)
Error code 8904
The back cover/duplex tray sensor detected that the cover was open during duplex printing.
(After registering printing data to engine)
 Error code 8A01
The registration rear sensor detected that the paper fed was smaller or larger than the
specified size in duplex printing mode.
2-sided Disabled
Close the Back Cover of the machine.
2-sided Disabled
Close the Back Cover of the machine.
<User Check>
• Close the back cover correctly.
Step Cause Remedy
1
Back cover/duplex tray sensor
attachment failure
Reattach the back cover/duplex tray sensor.
2
Boss to push the back cover/
duplex tray sensor is broken.
Replace the back cover.
3
Back cover/duplex tray sensor
failure
Replace the eject sensor PCB ASSY.
4
Main PCB failure Replace the main PCB ASSY.
Size Error DX
Specify the correct paper.
<User Check>
• Use appropriate paper (Letter to Legal).
Step Cause Remedy
1
Registration rear actuator
caught in some sections of the
machine
Reattach the registration rear actuator.
2
Registration rear sensor failure Replace the registration front/rear actuator
holder ASSY.
3
Main PCB failure Replace the main PCB ASSY.
