Brother MFC-L2700D Service Manual

2-49
Confidential
 Error code 9002
When printing from the paper tray, the size of paper set in the paper tray does not match the
size specified by the driver.
 Error code 9302
When printing from the paper tray, the paper feed sensor detected that there was no paper
set in the paper tray.
Error code 9307
Detected that paper has run out during receiving fax or printing a list/report.
Size mismatch
Reload correct paper, then press Start.
<User Check>
• Change the driver setting to be matched with the size of the paper set in the paper tray.
Step Cause Remedy
1
Registration rear actuator
caught in some sections of the
machine
Reattach the registration rear actuator.
2
Registration rear sensor failure Replace the registration front/rear actuator
holder ASSY.
3
Main PCB failure Replace the main PCB ASSY.
No Paper
Load paper.
No Paper
Load paper in Tray.
<User Check>
• Set paper in the paper tray.
Step Cause Remedy
1
Connection failure of the paper
feed sensor harness
Reconnect the paper feed sensor harness
ASSY.
2
Paper feed actuator caught in
sections of the machine
Reattach the paper feed actuator.
3
New toner sensor PCB failure Replace the new toner sensor PCB ASSY.
4
Main PCB failure Replace the main PCB ASSY.
